Описание

• Изходна мощност: 220 W
• Размер на високоговорителя: 8''
• Високочестотен високоговорител 1.35''
• Входове: XLR, 1/4 " TRS
• Честотна характеристика: 65 Hz - 20 kHz
• Честота на кросоувър: 24 kHz
• SPL (Макс.): 113 dB


Full Description

Class-D Amplifier Technology

The exceptional power and sonic performance from the B208D is down to the Class-D amplifier technology incorporated into the unit. The revolutionary technology is designed to provide powerful performance whilst not compromising on sound quality and overall clarity. The technology itself delivers optimal energy efficiency, which in-turn means there is no need for big power supplies and large heat sinks. This technology delivers the B208D's exceptional performance value with an impressive power-to-weight ratio.

Professional-Grade Components

On top of the Class-D amplifier technology built-in to this unit, the B208D features bi-amplification courtesy of the separately-powered drivers. Giving each woofer and tweeter a separate amplifier ensures the best possible signal integrity. The separate amplifiers are powered individually, giving you exceptional sonic performance whilst maintaining the clarity and depth of the sound, letting you hear every nuance in the audio.

Versatile, Portable Design

The B208D has been designed to be as versatile as possible, the actual construction itself has been created with a trapezoidal shape, giving you expansive mounting and positioning options. The trapezoidal shape is ideal for a range of applications from mounting on speaker poles, to being laid on their side for use as monitor wedges. Setting up is simple, only requiring a single XLR or 1/4'' cable connected to your mixer console and power supply. The XLR Link Output jack also gives you the option of linking multiple active monitors together to create an even more powerful system.

Features

• High-power 220-Watt 2-way PA sound reinforcement speaker system for live and playback applications
• Ultra-compact and light weight system delivers excellent sound even at extreme sound pressure levels
• Revolutionary Class-D amplifier technology: enormous power, incredible sonic performance and super-lightweight
• Internal switch-mode power supply for noise-free audio, superior transient response and very low power consumption
• Integrated sound processor for ultimate system control and speaker protection
• Extremely powerful 8'' long-excursion driver provides incredibly deep bass and acoustic power
• State-of-the-art 1.35'' aluminium-diaphragm compression driver for exceptional high-frequency reproduction
• Ultra-wide dispersion, large-format exponential/conical horn
• Ultra-low noise Mic/Line input with Volume control and Clip LED
• Additional Line output allows linking of additional speaker systems
• Versatile trapezoidal enclosure design allows different positioning
  • Stand mounting with 35-mm pole socket
  • Tilts on its side for use as a floor monitor
• High-quality components and exceptionally rugged construction ensure long life

Specifications

• Output Power: 220 Watts
• Speaker Size: 8 Inch
• Inputs: XLR, 1/4" TRS
• Input Sensitivity: -40 dBu to +4 dBu
• Input Impedance: 20 k Ohms
• Input Level (Max): +22 dBu
• Frequency Response: 65 Hz – 20 kHz
• Crossover Frequency: 24 kHz
• SPL (Max): 113 dB
• Limiter: Optical
• Dynamic Equalizer: Processor-Controlled
• Height: 14.72” / 374 mm
• Width: 9.8” / 249 mm
• Depth: 8.1” / 205 mm
• Weight: 6.8 Kg
