Описание

• Изходна мощност на усилвателя: Ниска честота: 135W RMS / 160W Peak @ 8Ω / Висока честота: 38W RMS / 42W Peak @ 8Ω
• Размер на НЧ високоговорителя: 10 ''
• Високочестотен високоговорител: 1.35 ''
• Честотна характеристика: 65Hz - 20kHz
• Честота на кросоувър: 2.4kHz
• Ниво на звуково налягане: 113dB SPL @ 1m
• XLR вход: Серво-балансиран
• 1/4 '' TRS Jack: Балансиран серво
• Конектор за връзка: XLR


Full Description

Class-D - Massive Power, Perfect Sound

Behringer's revolutionary Class-D amplifier technology allows you the B210D to deliver enormous power and outstanding sonic performance in an intuitive and lightweight package. Class-D amplification ensures energy efficiency while eliminating the need for heavy power supplies and heat sinks. This technology makes it possible to design and build extremely powerful products that are easy-to-use and significantly lighter in weight than their traditional counterparts.

Custom-Engineered Transducers

The design of the Behringer B210D features a 10'' low-frequency transducer and a 1.35'' compression driver, each of which have being engineered to perform flawlessly to ensure professional performance. Delivering 200W power output, the Behringer B210D produces massive low-end with articulate, detailed mids and crystal-clear highs.

Versatile, Portable Design

The B210D has been designed to be as versatile as possible, the actual construction itself has been created with a trapezoidal shape, giving you expansive mounting and positioning options. The trapezoidal shape is ideal for a range of applications from mounting on speaker poles, to being laid on their side for use as monitor wedges. Setting up is simple, only requiring a single XLR or 1/4'' cable connected to your mixer console and power supply. The XLR Link Output jack also gives you the option of linking multiple active monitors together to create an even more powerful system.

Features

• High-power 200 watt 2-way PA speaker for live and playback applications
• Ultra-compact and light weight system delivers excellent sound even at extreme sound pressure levels
• Revolutionary Class-D amplifier technology provides enormous power and incredible sonic performance
• Internal switch-mode power supply for noise-free audio, superior transient response and very low power consumption
• Integrated sound processor for ultimate system control and speaker protection
• Extremely powerful 10'' long-excursion driver provides incredibly deep bass and acoustic power
• State-of-the-art 1.35'' aluminium-diaphragm compression driver for exceptional high-frequency reproduction
• Ultra-wide dispersion
• Ultra-low noise Mic/Line input with volume control and clip LED
• Additional Line output allows linking of additional speaker systems
• Versatile trapezoidal enclosure design allows either stand mounting via 35mm pole socket or vertical floor monitoring
• Ergonomically shaped handles for easy carrying and setup
• Designed and engineered in Germany

Specifications

• Amplifier Power Output:
  • Low-Frequency: 135W RMS / 160W Peak @ 8Ω
  • High-Frequency: 38W RMS / 42W Peak @ 8Ω
• Speaker Size: 10''
• Tweeter Size: 1.35''
• Frequency Response: 65Hz - 20kHz
• Crossover Frequency: 2.4kHz
• Sound Pressure Level: 113dB SPL @ 1m
• Limiter: Optical
• Dynamic EQ: Processor-Controlled
• Equalizer:
  • High: 12kHz / ±15dB
  • Low: 80Hz / ±15dB
• XLR Input: Servo-Balanced
  • Sensitivity: -40dBu to +4dBu
  • Impedance: 20kΩ
• 1/4'' TRS Jack: Servo-Balanced
  Sensitivity: -40dBu to +4dBu
  • Impedance: 20kΩ
• Maximum Input Level: +22dBu
• Link Connector: XLR
• Dimensions: 18.34'' x 11.50'' x 9.61'' / 466mm x 292mm x 244mm (H x W x D)
• Weight: 19.18lbs / 8.7kg
