Full Description

Smooth Control Settings

The Ultraglide channel faders on the DX626 mixer allow for incredibly precise level settings and are designed for heavy use (500,000 cycles) whilst a VCA crossfader ensures a reliable performance.

Focused Vocal Performance

The DX626 features a dedicated mic input and an integrated talkover function, allowing users to lower the volume of their music so vocals can take centre stage. Vocals are adjustable via the on-board 3-band EQ, giving 15 dB of boost or cut at low, mid and high frequencies.

Simple Track Syncing

With built-in dual auto BPM counters, syncing up tracks becomes incredibly easy. The counters provide a smooth track transition with a digital display showing channel tracking and the tempo of the music (beats per minute). Users can manually enter the tempo via the 'beat assist' button and receive a readout of the tempo difference between the tracks, and confirmation of when they are in sync.

Features

• Professional 3-channel ultra-low noise DJ mixer with state-of-the-art phono preamps
• Intelligent, dual BPM counter
• Super smooth, long-life Ultraglide faders (up to 500,000 cycles)
• VCA-controlled crossfader for utmost reliability & smooth audio performance
• 3-band kill EQ (-32 dB) & gain control per channel
• Manual talkover function
• Microphone input with studio-grade ULN technology
• Monitor function with master/PFL mix option
• Precise peak-hold level metre with dedicated PFL bar graph
• BNC gooseneck lamp socket
• Gold-plated RCA connectors for highest signal integrity

Specifications

• Inputs
  • Mic: 40 dB Gain, Electronically Balanced Input
  • Phono 1, 2 and 3: 40 dB Gain @ 1kHz, Unbalanced Inputs
  • Line 1, 2 and 3: 0 dB Gain, Unbalanced Inputs
• Outputs
  • Master: Max. +21 dBu @ +10 dB (Line In)
  • Booth: Max. +21 dBu @ +10 dB (Line In)
  • Tape: Type 0 dBu
  • Phones: Type 125 mΩ @ 1 Percent THD
• Equaliser (+/- 8dB)
  • Stereo Low: +12 dB / -32 dB @ 50Hz
  • Stereo Mid: +12 dB / -32 dB @ 1.2kHz
  • Stereo High: +12 dB / -32 dB @ 10kHz
  • Mic Low: + 12 dB / -32 dB @ 50Hz
  • Mic Mid: +12 dB / -32 dB @ 1.2kHz
  • Mic High: + 12 dB / -32 dB @ 10kHz
• Talkover Button (Mic): -16 dB
• Lamp (BNC): 12 V/400 mA
• General
  • Signal-To-Noise Ratio (S/N): > 87 dB
  • Crosstalk: > 70 dB (Line)
  • Distortion (THD): >0.05 Percent
  • Frequency Response: 20Hz - 20kHz
  • Gain Control Range: -16 dB- + 6 dB
• Power Supply
  • USA/Canada: 120V, 60Hz
  • UK/Australia: 240V, 50Hz
  • Europe: 230V, 50Hz
  • General Export Model: 100-120V, 200-240V, 50/60Hz
• Power Consumption: Max 15W
• Mains Connection: Standard IEC Receptacle
• Weight: 2.6 kg
• Dimensions
  • Height: 91 mm
  • Width: 254 mm
  • Depth: 305 mm
